Lavezzini TOP Chamber Vacuum Sealer – 450 mm Sealing Bar, 20 m³/h, 230 V – 570 × 660 × 530 mm
SKU: CX-LvZTOP45 · Weight: 90 kg
excl. VAT · per unit
Description
The Lavezzini TOP chamber vacuum sealer is designed for professional packaging operations in restaurants, butcher shops and food production facilities. With a 470 × 530 × 220 mm vacuum chamber and a 450 mm sealing bar, it offers space for various bag formats.
The oil-lubricated vacuum pump delivers 20 m³/h displacement. 20 user programs allow you to save settings for recurring packaging tasks. Equipment also includes Clean Pump, Gastrovac System, Step Vac, Soft Vac and Extra Vac.
Various optional features enable adaptation to operational requirements. These include inert gas flushing, vacuum sensor, additional sealing bars and a larger vacuum pump.
Product Benefits:
Vacuum chamber with 470 × 530 × 220 mm internal dimensions
450 mm sealing bar
Oil-lubricated vacuum pump with 20 m³/h displacement
20 user programs for recurring workflows
Clean Pump, Gastrovac System, Step Vac, Soft Vac and Extra Vac
Membrane sealing system
Extensive optional equipment
Technical Specifications:
Property | Value |
|---|---|
Brand | Lavezzini |
Model | TOP |
Product Type | Chamber vacuum sealer |
External Dimensions (W × D × H) | 570 × 660 × 530 mm |
Chamber Dimensions (W × D × H) | 470 × 530 × 220 mm |
Sealing Bar Length | 450 mm |
Vacuum Pump Displacement | 20 m³/h |
Pump Type | Oil-lubricated |
Sealing System | Membrane sealing |
User Programs | 20 |
Power Supply | 230 V / 50 Hz |
Weight | 90 kg |
Optional Equipment – Not Included in Standard Configuration:
Inert gas flushing
Label printer
Busch vacuum pump
Larger vacuum pump
Vacuum sensor
Additional sealing bar
Bioactive sealing bar
Pneumatic sealing system / Piston sealing system
Bag excess trimming
Chamber lid locking system
Increased chamber height
Angled insertion plate for liquids
Gas diffuser with 6, 8, 10 or 12 nozzles
Special versions for voltage and frequency
