WashPro Full Hygiene 500 | Professional Pass-Through Dishwasher 1080 Plates/h – AISI 304, 8.7 kW
SKU: CX-PRMY505HYG
excl. VAT · per unit
Description
WashPro Full Hygiene 500 is a professional pass-through dishwasher of the latest generation – designed for high-performance use in restaurants, hotels, canteens, and catering operations. With a capacity of up to 1,080 plates per hour (30–60 racks/h) and the innovative “Full Hygiene” concept, it sets new standards in cleanliness, efficiency, and food safety.
The fully AISI 304 stainless steel double-walled insulated casing ensures maximum hygiene and durability. The patented Diamond® hood system enables particularly easy and ergonomic operation. Thanks to the integrated Break-Tank system (Type AB), backflow contamination of fresh water is reliably prevented – a crucial advantage for the highest hygiene standards according to British and European norms.
The digital CSD soft-touch control panel with an integrated self-diagnosis system (DID) and HACCP-compliant temperature display makes operation intuitive and maintenance simple. The exclusive SANITISATION program ensures thermal disinfection at over 70 °C with an A0 lethality index above 30 – far exceeding the standard of conventional dishwashers (EN 15883).
Your Benefits at a Glance
- 🍽️ 1,080 plates/hour – Maximum throughput for large operations
- 🦠 SANITISATION program – Thermal disinfection according to EN 15883, A0 > 30
- 💧 Break-Tank system (Type AB) – Prevents backflow contamination, guarantees 85 °C rinse temperature
- 🌍 Save the Planet – Minimal water, energy, and detergent consumption
- 🔧 Self-diagnosis (DID) – Automatic fault detection for minimal downtime
- 📊 HACCP-compliant – Temperature display for tank & boiler always in view
- ✨ Fully AISI 304 stainless steel – Hygienic, robust, and durable
Technical Specifications
| Feature | Specification |
|---|---|
| Rack size | 500 x 500 mm |
| Capacity | 1,080 plates/h / 30–60 racks/h |
| Programs | 60", 110", 150", continuous, Sanitisation |
| External dimensions (WxDxH) | 710 x 800 x 1530/2010 mm |
| Power consumption | 8.7 kW |
| Voltage | 400–230 V / 3N / 50 Hz |
| Wash tank | 20 liters / 2.5 kW |
| Boiler | 12 liters / 8 kW (stainless steel) |
| Water consumption/cycle | 3 liters |
| Rinse temperature | 85 °C (guaranteed, constant) |
| Material | AISI 304 stainless steel, double-walled insulated |
| Gross weight | 132 kg |
| Delivery contents | 3 racks, 1 cutlery basket, 2 peristaltic dispensers |
Included Technology Features
| Acronym | Function |
|---|---|
| CSD | Digital soft-touch control panel |
| EED | Energy optimization |
| TCD | Thermostat control – guaranteed 85 °C rinse |
| DRD | Rapid heating |
| DID | Self-diagnosis for faults |
| ADD | HACCP temperature display for tank & boiler |
| CAD | Self-cleaning cycle |
| BTD | Break-Tank anti-contamination system Type AB |
